QP-150-3B 150W Four-Way PFC Power Supply

InverterPower SupplyModel: QP-150-3BType: AC/DC power supplyModulation method: Pulse width modulation (PWM) typeTransistor connection method: single-endedInput voltage: 90～264VAC/127～370VDCOutput power: 150Output voltage: +5/ +3.3/ 12/ -12Work efficiency: 75Output ripple noise: 100mV / 100mV / 150mV / 150mVOutput voltage accuracy: ±3 / ±3 / ±6 / ±5Load regulation: +-2~6Product certification: CCCOutput current: 15A/15A/5A/1AWorking frequency: 47~63Working temperature: -10~60Overall dimensions: 199*90*50MMMaterial number: QP-150-3BOrder number: QP-150-3BMinimum number of packages: 1Specifications: QP-150-3BSeries: QP-150Number of power supply phases: four phasesInput voltage range: 90～264VAC/127～370VDCNumber of circuits: single circuitScope of application: Mechanical and equipment driveExtended functions: mechanical machine toolsWorking environment temperature: -10~60Installation method: screw installationRemarks: Unless otherwise specified all specifications and parameters are measured at an input of 230VAC rated load and an ambient temperature of 25°C.Reset method: power off and restartAdjust voltage: potentiometer adjustmentCooling fan type: forced air coolingPower supply type: switching power supplyQP-150-3B■ Product DescriptionThe power supply model with high power factor is a must-select model in Europe. Built-in active power factor correction circuit (PFC) helps improve energy utilization and reduce harmonic interference. It has a global full range of voltage input and complete functions.QP-150-3B■ Main featuresFull range AC input voltageBuilt-in active power factor correction circuit power factor: PF>0.98 at 115VAC; PF>0.95 at 230VACWith short circuit protection/overload protection/overvoltage protectionInternational safety certification: UL/TUV/CB/CEF
